General

Rig Name             TPS Rig 7

Rig Category          Work over

Rig Type              Mobile Fast move

Rig HP                900

Year Built            Rebuilt 2016

Manufacturer          US

Rated Drilling Depth  12000 ft.

Rig Move Loads        30



Drilling Equipment

Mast height           112 ft.

Hook Load             155 ton

Setback Load          100 ton

Rotary Table          National 20 1/2 INCH CABOT FRANKS

Drawworks             2346 ED 1 1/8 INCH

Drilling Line         Kelly

Top Drive / Kelly     National

Mud Pumps                  (2 EA Triplex pump)

Main Power Supply       2 EA CATERPILLAR 3406 Diesel

Emergency Power Supply  N/A



Well Control Equipment

Annular BOP                  Hydril 11 INCH x 5,000 PSI WP

Single BOP                    N/A

Double BOP                   SHAFFER 11 INCH x 5000 PSI WP

Choke & Kill Manifolds     CAMERON 5,000 PSI WP

Accumulator Unit             4 Station - 3,000 PSI WP - 8 x 11 Gallon Bottles



Down Hole Equipment

Drill Pipes                  3 1/2 IN

Drill Collars                4 3/4 IN



Storage Facilities

Liquid Mud                 1000 BBLS

Drill Water                 500 BBLS

Rig Site                     Main Camp

Fuel                          70
BBLS                        100

Fresh Water              18
BBLS                        100

Camp Capacity           65 persons
